// GEM - Graphics Environment for Multimedia
//
// mark@danks.org
//
// Implementation file
//
//    Copyright (c) 1997-1999 Mark Danks.
//    For information on usage and redistribution, and for a DISCLAIMER OF ALL
//    WARRANTIES, see the file, "GEM.LICENSE.TERMS" in this distribution.
//
/////////////////////////////////////////////////////////

#include "pix_video.h"

#include "Base/GemCache.h"
#include "Base/GemMan.h"
#include "Base/GemWinCreate.h"

CPPEXTERN_NEW_WITH_ONE_ARG(pix_video, t_floatarg, A_DEFFLOAT)
// CPPEXTERN_NEW(pix_video)

/////////////////////////////////////////////////////////
//
// pixvideo
//
/////////////////////////////////////////////////////////
// Constructor
//
/////////////////////////////////////////////////////////
pix_video :: pix_video(t_floatarg num)
    	   : m_haveVideo(0), m_swap(1), m_colorSwap(0),
			 m_hWndC(NULL), m_newFrame(0)
{
    m_pixBlock.image.data = NULL;

	// set to half PAL
	if (num)
	{
		m_vidXSize = 320;
		m_vidYSize = 240;
	}
	// set to half NTSC
	else
	{
		m_vidXSize = 320;
		m_vidYSize = 240;
	}

    // Connect to the daemon
	m_hWndC = capCreateCaptureWindow (
		(LPSTR) "GEM video",	// window name if pop-up
		0,						// window style (not visible)
		0, 0, m_vidXSize, m_vidYSize,         // window position and dimensions
		GetDesktopWindow(), 0);
	if (!m_hWndC)
	{
		error("GEM: pix_video: Unable to create capture window");
		return;
	}

	if (!capDriverConnect(m_hWndC, 0))
	{
		error("GEM: pix_video: Unable to connect to video driver");
		return;
	}

	CAPTUREPARMS params;
	if (!capCaptureGetSetup(m_hWndC, &params, sizeof(CAPTUREPARMS)))
	{
		error("GEM: pix_video: Unable to get capture parameters");
		return;
	}
	params.fYield = TRUE;
	params.fCaptureAudio = FALSE;
	params.wPercentDropForError = 100;
	params.fLimitEnabled = FALSE;
	params.AVStreamMaster = AVSTREAMMASTER_NONE;
	params.fStepCaptureAt2x = FALSE;
	params.fAbortLeftMouse = FALSE;
	params.fAbortRightMouse = FALSE;
	if (!capCaptureSetSetup(m_hWndC, &params, sizeof(CAPTUREPARMS)))
	{
		error("GEM: pix_video: Unable to set capture parameters");
		return;
	}

	if (!capSetCallbackOnVideoStream(m_hWndC, pix_video::videoFrameCallback))
	{
		error("GEM: pix_video: Unable to set frame callback");
		return;
	}
	if (!capSetUserData(m_hWndC, this))
	{
		error("GEM: pix_video: Unable to set user data");
		return;
	}
	DWORD formSize = capGetVideoFormat(m_hWndC, NULL, 0);
	BITMAPINFO *videoFormat = (BITMAPINFO *)(new char[formSize]);
	if (!capGetVideoFormat(m_hWndC, videoFormat, formSize))
	{
		error("GEM: pix_video: Unable to get video format");
		return;
	}

	videoFormat->bmiHeader.biWidth = m_vidXSize;
	videoFormat->bmiHeader.biHeight = m_vidYSize;
	videoFormat->bmiHeader.biBitCount = 24;
	videoFormat->bmiHeader.biCompression = BI_RGB;
	videoFormat->bmiHeader.biClrUsed = 0;
	videoFormat->bmiHeader.biClrImportant = 0;
	videoFormat->bmiHeader.biSizeImage = 0;
	if (!capSetVideoFormat(m_hWndC, videoFormat, formSize))
	{
		error("GEM: pix_video: Unable to set video format");
		return;
	}
	post("GEM: pix_video: Connected at x: %d, y: %d, c: %d",
			(int)(videoFormat->bmiHeader.biWidth),
			(int)(videoFormat->bmiHeader.biHeight),
			(int)(videoFormat->bmiHeader.biBitCount));
	delete videoFormat;

    m_pixBlock.image.xsize = 128;
    m_pixBlock.image.ysize = 128;
    m_pixBlock.image.csize = 4;
    m_pixBlock.image.format = GL_RGBA;
    m_pixBlock.image.type = GL_UNSIGNED_BYTE;
    const int dataSize = m_pixBlock.image.xsize * m_pixBlock.image.ysize
    	    	     * m_pixBlock.image.csize * sizeof(unsigned char);
    m_pixBlock.image.data = new unsigned char[dataSize];
	memset(m_pixBlock.image.data, 255, dataSize);

	m_haveVideo = 1;
}

/////////////////////////////////////////////////////////
// Destructor
//
/////////////////////////////////////////////////////////
pix_video :: ~pix_video()
{
	if (!m_hWndC)
		return;

    stopTransfer();
	capDriverDisconnect(m_hWndC);
    DestroyWindow(m_hWndC);

    // Clean up the video
    if (m_haveVideo)
    {
    	post("GEM: pix_video: Closed video connection");
    }
    cleanPixBlock();
}

/////////////////////////////////////////////////////////
// videoFrame
//
/////////////////////////////////////////////////////////
void pix_video :: videoFrame(LPVIDEOHDR lpVHdr)
{
	int count = lpVHdr->dwBytesUsed;
	// notice that it is times 3 for the color!
	const int dataSize = m_pixBlock.image.xsize * m_pixBlock.image.ysize * 3;

	if (count < dataSize)
	{
		error("GEM: pix_video: not enough pixels captured");
		return;
	}

	const unsigned char *srcLine = lpVHdr->lpData;
	unsigned char *dstLine = m_pixBlock.image.data;
	const int srcXSize = m_vidXSize * 3;
	const int dstXSize = m_pixBlock.image.xsize * 4;
	const int xSize = m_pixBlock.image.xsize;
	const int ySize = m_pixBlock.image.ysize;

	for (int i = 0; i < ySize; ++i)
	{
		const unsigned char *srcPix = srcLine;
		unsigned char *dstPix = dstLine;
		for (int j = 0; j < xSize; ++j)
		{
			dstPix[chRed] = srcPix[2];
			dstPix[chGreen] = srcPix[1];
			dstPix[chBlue] = srcPix[0];
// remember that we memset the data to 255
//			dst[chAlpha] = 255;
			dstPix += 4;
			srcPix += 3;
		}
		srcLine += srcXSize;
		dstLine += dstXSize;
	}
	m_newFrame = 1;
}

/////////////////////////////////////////////////////////
// render
//
/////////////////////////////////////////////////////////
void pix_video :: render(GemState *state)
{
	if (!m_haveVideo)
    {
		error("GEM: pix_video: Video not active");
		return;
    }

	m_pixBlock.newimage = m_newFrame;
    state->image = &m_pixBlock;
	m_newFrame = 0;
}

/////////////////////////////////////////////////////////
// startRendering
//
/////////////////////////////////////////////////////////
void pix_video :: startRendering()
{
	if (!capCaptureSequenceNoFile(m_hWndC))
	{
		error("GEM: pix_video: Unable to start capture");
		return;
	}

    m_pixBlock.newimage = 1;
}

/////////////////////////////////////////////////////////
// stopRendering
//
/////////////////////////////////////////////////////////
void pix_video :: stopRendering()
{
	capCaptureStop(m_hWndC);
}

/////////////////////////////////////////////////////////
// postrender
//
/////////////////////////////////////////////////////////
void pix_video :: postrender(GemState *state)
{
    m_pixBlock.newimage = 0;
    state->image = NULL;
}

/////////////////////////////////////////////////////////
// startTransfer
//
/////////////////////////////////////////////////////////
int pix_video :: startTransfer()
{
    if (!m_haveVideo)
		return(0);
	return(1);
}

/////////////////////////////////////////////////////////
// stopTransfer
//
/////////////////////////////////////////////////////////
int pix_video :: stopTransfer()
{
    if ( !m_haveVideo )
		return(0);

    // Clean up the buffer

    return(1);
}

/////////////////////////////////////////////////////////
// offsetMess
//
/////////////////////////////////////////////////////////
void pix_video :: offsetMess(int x, int y)
{
	post("GEM: pix_video: offset message not supported");
	return;

    if (!m_haveVideo)
    {
    	error("GEM: pix_video: Connect to video first");
    	return;
    }

    // stop the transfer and destroy the buffer
    if ( !stopTransfer() )
    {
    	error("GEM: pix_video: error stopping transfer");
    	return;
    }

    // start the transfer and rebuild the buffer
    if ( !startTransfer() )
    {
		error("GEM: pix_video: error starting transfer");
    	return;
    }
}

/////////////////////////////////////////////////////////
// dimenMess
//
/////////////////////////////////////////////////////////
void pix_video :: dimenMess(int x, int y)
{
    if (!m_haveVideo)
    {
    	error("GEM: pix_video: Connect to video first");
    	return;
    }

    // stop the transfer and destroy the buffer
    if ( !stopTransfer() )
    {
    	error("GEM: pix_video: error stopping transfer");
    	return;
    }

    m_pixBlock.image.xsize = x;
    m_pixBlock.image.ysize = y;

    cleanPixBlock();
    int dataSize = m_pixBlock.image.xsize * m_pixBlock.image.ysize
    	    	    * 4 * sizeof(unsigned char);
    m_pixBlock.image.data = new unsigned char[dataSize];
	memset(m_pixBlock.image.data, 255, dataSize);

    // start the transfer and rebuild the buffer
    if ( !startTransfer() )
    {
    	error("GEM: pix_video: error starting transfer");
    	return;
    }
}

/////////////////////////////////////////////////////////
// cleanPixBlock
//
/////////////////////////////////////////////////////////
void pix_video :: cleanPixBlock()
{
    delete [] m_pixBlock.image.data;
    m_pixBlock.image.data = NULL;
}

/////////////////////////////////////////////////////////
// swapMess
//
/////////////////////////////////////////////////////////
void pix_video :: swapMess(int state)
{
	post("GEM: pix_video: swap message not supported");
	return;

    if (state)
		m_swap = 1;
    else
		m_swap = 0;
}

/////////////////////////////////////////////////////////
// static member function
//
/////////////////////////////////////////////////////////
void pix_video :: obj_setupCallback(t_class *classPtr)
{
    class_addmethod(classPtr, (t_method)&pix_video::dimenMessCallback,
    	    gensym("dimen"), A_FLOAT, A_FLOAT, A_NULL);
    class_addmethod(classPtr, (t_method)&pix_video::offsetMessCallback,
    	    gensym("offset"), A_FLOAT, A_FLOAT, A_NULL);
    class_addmethod(classPtr, (t_method)&pix_video::swapMessCallback,
    	    gensym("swap"), A_FLOAT, A_NULL);
}
void pix_video :: dimenMessCallback(void *data, t_floatarg x, t_floatarg y)
{
    GetMyClass(data)->dimenMess((int)x, (int)y);
}
void pix_video :: offsetMessCallback(void *data, t_floatarg x, t_floatarg y)
{
    GetMyClass(data)->offsetMess((int)x, (int)y);
}
void pix_video :: swapMessCallback(void *data, t_floatarg state)
{
    GetMyClass(data)->swapMess((int)state);
}

void pix_video :: videoFrameCallback(HWND hWnd, LPVIDEOHDR lpVHdr)
{
	void *ptr = (void *)(capGetUserData(hWnd));
	((pix_video *)ptr)->videoFrame(lpVHdr);
}
